why choose newtek
Ease of Operation and Low Maintenance
User-Friendly Design
The system is designed with simplicity in mind. Operators can easily monitor and control oxygen production through a digital interface, which provides real-time data on oxygen levels, purity, and system status.
Automation for Maximum Efficiency
The oxygen generation process is automated, reducing the need for manual intervention. The system automatically adjusts oxygen production based on demand and shuts down safely in the event of any malfunction.
Low Maintenance Requirements
Designed for the demanding conditions of gold mining operations, the Oxygen Generation for Gold Leaching system is built to last.
Remote Monitoring
The system comes equipped with remote monitoring capabilities, enabling real-time tracking of oxygen production and system performance from any location.
On-Site Oxygen Generation
Traditional methods rely on purchasing and transporting oxygen cylinders, which can be costly and logistically complex. Our system eliminates these issues by generating oxygen on-site, ensuring a continuous, reliable supply without external dependencies. This on-site production minimizes disruptions and reduces transportation and storage costs associated with traditional oxygen supply methods.
Enhanced Gold Recovery and Processing Speed
With a steady supply of high-purity oxygen, the system optimizes the cyanide leaching process. The enhanced oxygen levels promote faster gold dissolution, leading to a higher recovery rate, reduced chemical consumption, and shorter processing times. This, in turn, increases operational efficiency and boosts profitability.
Oxygen Generation For Gold Leaching Model
| Models | Capacity (Nm3/hr) | Purity | Power consumption of 1Nm3 oxygen produced (kw/h) | Number of bottles filled in 12 hours (pcs) | Operator needed |
| NTK-5P | 5 | 95%+-1% | 3.54 | 10 | 2 |
| NTK-10P | 10 | 95%+-1% | 2.52 | 20 | 2 |
| NTK-15P | 15 | 95%+-1% | 2.31 | 30 | 2 |
| NTK-20P | 20 | 95%+-1% | 2.13 | 40 | 2 |
| NTK-25P | 25 | 95%+-1% | 2.01 | 50 | 2 |
| NTK-30P | 30 | 95%+-1% | 2.09 | 60 | 2 |
| NTK-40P | 40 | 95%+-1% | 1.81 | 80 | 2 |
| NTK-50P | 50 | 95%+-1% | 1.94 | 100 | 2 |
| NTK-60P | 60 | 95%+-1% | 1.62 | 120 | 2 |
| NTK-80P | 80 | 95%+-1% | 1.92 | 160 | 2 |
| NTK-100P | 100 | 95%+-1% | 1.83 | 200 | 2 |
| Design basis: Altitude:500m;RH:80%;Temperature：0℃-38℃;Filling pressure:150Bar 40L Type Standard Cylinder | |||||
FAQ
Q: What kind of cost savings can we expect from using the Oxygen Generation system?
A: By switching to on-site oxygen generation, you can expect significant cost savings in several areas. First, you'll eliminate the need for ongoing purchases and transportation of oxygen cylinders, which can be costly, especially for large-scale operations. Second, the improved efficiency of the leaching process means you'll achieve higher gold recovery rates with reduced chemical consumption, further lowering operational costs. Over time, the return on investment (ROI) from switching to on-site oxygen generation can be substantial, making it a cost-effective long-term solution for gold mining operations.
Q: Can Oxygen Generation For Gold Leaching be used in remote mining locations with limited infrastructure?
A: Yes, the Oxygen Generation system is an ideal solution for remote mining sites with limited infrastructure. Since it generates oxygen on-site, there is no need to rely on external deliveries or large storage tanks, which are often challenging to manage in remote locations. The system is designed to operate efficiently in harsh environments and can be remotely monitored for performance, ensuring reliable operation even in off-grid areas. This makes it perfect for operations in regions where logistics and supply chain challenges are common.
Q: How energy-efficient is the Oxygen Generation system?
A: The Oxygen Generation system is designed with energy efficiency in mind. It operates with minimal energy consumption while delivering high-purity oxygen at a consistent rate. The system's energy-efficient design helps keep operating costs low while ensuring that your mining operations run smoothly. Additionally, because it reduces reliance on external suppliers, it also minimizes the environmental impact of oxygen transportation, making it a sustainable option for mining companies looking to reduce their carbon footprint.
