Product Description

The containerized nitrogen plant is a highly compact and fully integrated nitrogen production system designed specifically for rapid on-site production of high-purity nitrogen. This innovative solution loads all necessary equipment and components into a standard container, making it extremely flexible and portable. The containerized nitrogen plant is particularly suitable for industries that require high reliability and efficiency in nitrogen supply, such as electronics manufacturing, chemicals, pharmaceuticals, and food processing.

The advantage of this system is that it can be quickly installed and commissioned on-site, avoiding the transportation delays and increased costs that may be caused by traditional nitrogen delivery methods. Users only need to connect the container to the power supply and gas source to start producing nitrogen immediately, greatly improving production efficiency. At the same time, the protective performance of the container design can also ensure the normal operation of the equipment under various environmental conditions, whether in the cold north or the hot south, the equipment can maintain stable production capacity.

How the product works

Containerized nitrogen generators don't actually produce nitrogen. Instead, they use nitrogen that's already in the air and concentrate it by removing excess molecules. The typical composition of air is 78% nitrogen and 21% oxygen. There are also small amounts of other molecules, such as carbon dioxide, argon, and water.

What removes the excess molecules from the air is pressure swing adsorption (PSA) technology, which removes unwanted (i.e., non-nitrogen) molecules. The operating principle is simple. After air is drawn in from the intake valve, it is passed through a carbon molecular sieve (CMS). The CMS has small pores throughout its surface, which is the ideal size for oxygen molecules. Nitrogen molecules are larger than oxygen molecules, so they don't adsorb to the material and pass through the CMS undisturbed. (Various experiments have shown that the diameter of a nitrogen molecule is about 0.2 angstroms longer than the diameter of oxygen. An angstrom is about one billionth of a meter.)

Like some adsorption air dryers, PSA nitrogen generators have two chambers. One has a new CMS for the current adsorption process, and the other swings to low pressure to desorb oxygen from the saturated CMS. The containerized nitrogen generator can produce up to 99.999% pure nitrogen.

productcate-1553-449

Container Type Nitrogen Plant
Container type nitrogen plant is a device that can produce nitrogen in a mobile state, usually composed of a container and nitrogen production equipment. It mainly separates oxygen and other impurities in the air through compressed air and
read more
Containerized Nitrogen Plant
PSA nitrogen generator is a device used to generate high-purity nitrogen from compressed air. Its working principle is based on the principle of Pressure Swing Adsorption (PSA). It is mainly composed of an intake system, an adsorber, a gas
read more
Containerized PSA Nitrogen Generator
The advantages of producing your own nitrogen are clear compared to purchasing it. You can control the gas supply at a lower cost and with a lower emissions footprint, and reduce logistical issues and safety concerns. But what if you
read more

Standard configuration

1. ASME adsorption vessel

The ASME (American Society of Mechanical Engineers) certified adsorption vessel is one of the core components of the containerized PSA nitrogen generator. ASME certification ensures the manufacturing quality and safety of the adsorption vessel, which can withstand high pressure and frequent pressure fluctuations. The adsorption vessel is filled with high-performance adsorption media, usually carbon molecular sieves, which can effectively separate nitrogen and oxygen in the air. High-performance adsorption media can provide excellent nitrogen purity and output, while having a long service life.

2. High-cycle life pneumatic/electric valve

Pneumatic or electric valves with high cycle life are constantly opened and closed during system operation to control the path of airflow and the switching of adsorption process. High-quality pneumatic or electric valves can withstand frequent operations, ensure the reliability and stability of the system, and extend the service life of the equipment.

3. Oxygen analyzer with calibration kit

This is an indispensable monitoring device in the nitrogen generator. The oxygen analyzer monitors the oxygen content in the nitrogen in real time to ensure that the produced nitrogen meets the predetermined purity standard. The calibration kit can calibrate the analyzer regularly to ensure the accuracy of its measurement, thereby ensuring the quality of each batch of nitrogen in the production process.

4. Pressure safety valve

The pressure safety valve is an important component to ensure the safety of equipment and operators. When the internal pressure of the system exceeds the preset value, the pressure safety valve will automatically open to release excess pressure to prevent equipment damage or safety accidents. The setting and maintenance of the pressure safety valve are directly related to the safe operation of the equipment and are essential safety devices in the nitrogen generator.

5. Nitrogen pressure regulator

The nitrogen pressure regulator is used to adjust and stabilize the output nitrogen pressure to meet the needs of different application scenarios. Whether in chemical production, food packaging or electronic component manufacturing, stable nitrogen pressure is a key factor to ensure the smooth progress of the production process. High-precision pressure regulators can provide stable and reliable nitrogen pressure output to meet various fine production requirements.

6. PLC control system

The PLC (programmable logic controller) control system is the "brain" of the containerized PSA nitrogen generator. The PLC control system can automatically manage and coordinate the entire nitrogen production process, including functions such as airflow switching, pressure regulation and fault alarm. Through the PLC control system, operators can easily monitor and adjust equipment operating parameters to improve production efficiency and the intelligence level of equipment.

7. Carbon steel slide rails

Carbon steel slide rails provide a solid installation foundation for the nitrogen generator. Carbon steel has excellent mechanical strength and corrosion resistance, and can withstand the vibration and impact generated during the operation of the equipment, ensuring that the equipment can operate stably in various environments.

8. Exhaust muffler

The exhaust muffler is an important component used to reduce the noise generated during the operation of the equipment and improve the working environment. The container-type PSA nitrogen generator will generate large airflow noise during the adsorption and desorption process. The exhaust muffler can effectively reduce this noise and provide a quiet operating environment.

Product Features and Advantages

Simple and fast installation

Pre-installed internal cables: The modular nitrogen generator has pre-installed internal cables before leaving the factory. Users only need to connect one incoming cable. This design greatly simplifies the installation process and eliminates the tedious steps of on-site wiring. Users do not need to have complex electrical knowledge to successfully complete the installation of the equipment. In addition, the pre-installed cable system ensures that all connections are rigorously tested, avoiding equipment failures caused by wiring errors. Users can complete the installation in a short time and put it into use quickly, which significantly improves work efficiency and saves time and labor costs.

Flexible and convenient operation

One-button operation start: The device adopts an advanced human-machine interface design. Users only need to press a button to start and run the entire system. This one-button operation method makes it easy for even operators who lack professional skills to get started, greatly reducing the complexity of operation. At the same time, the simplified operation process improves work efficiency and reduces downtime caused by improper operation.

Start each device according to the regulations: In addition to the convenient one-button start, the device also supports starting each device one by one according to the regulations. Users can flexibly adjust the startup sequence of the equipment according to production needs, which is particularly important when dealing with different workloads. This flexibility not only improves production flexibility, but also ensures the safe operation of the equipment and avoids the risk of failure caused by sudden load increase.

Controllable operation records

Online data recording: During operation, the equipment will automatically record various operation data, including key parameters such as flow, pressure, and temperature, at the set time. This online data recording function enables users to grasp the operating status of the equipment in real time, discover potential problems in time and make adjustments. At the same time, the recording and storage of these data provides a valuable basis for subsequent equipment maintenance and management.

Remote monitoring option: In order to improve management efficiency, the equipment can also be equipped with a remote monitoring function. Users can monitor the operating status of the equipment in real time through the Internet, and view real-time data and historical records. This remote monitoring capability not only improves the management efficiency of the equipment, but also provides strong support for the intelligent management of the enterprise. Users can effectively monitor the equipment at different locations and times and respond in time.

Adjustable flow purity

Multiple purity and flow requirements: The equipment has the function of flexibly adjusting flow and purity to meet the needs of different industries and application scenarios. Whether it is the production of high-purity nitrogen or the demand for regular flow, the equipment can meet it efficiently. This flexibility allows users to adjust according to specific production requirements to ensure that the quality and performance of the gas are always optimal. For example, in the pharmaceutical industry, the purity requirements for nitrogen are extremely high, while in other industries, users may have more important requirements for flow. The flexible adjustment ability of the equipment allows users to easily cope with these different requirements.

Adaptability to harsh environments

High and low temperature and sand and dust adaptability: The modular nitrogen generator is specially designed to operate stably in harsh environments such as high temperature, low temperature and sand and dust. This environmental adaptability ensures that the equipment can still maintain normal operation under various extreme conditions, providing users with year-round production guarantees. Whether in hot summer or cold winter, even in dusty construction sites, the equipment can operate efficiently, thereby greatly improving users' production efficiency and economic benefits.

Adaptability to multiple uses

Vehicle-mounted and ground applications: The design of the device is flexible and diverse, not only suitable for fixed ground applications, but also can be configured as a vehicle. This dual adaptability enables the equipment to work effectively in a variety of occasions and adapt to different business needs. Whether it is a mobile field operation or a long-term operation in a fixed plant, modular nitrogen generators can provide an ideal solution.

Reserved auxiliary interface

User-customized interface: In order to meet the personalized needs of users, multiple auxiliary interfaces are reserved during the design of the equipment. These interfaces can be customized according to user requirements, allowing the addition of external lighting interfaces, wind vane bases, etc. This design flexibility not only enhances the functionality of the equipment, but also improves the convenience of users in specific applications. For example, when working outdoors, the external lighting interface can ensure sufficient lighting during night operations, while the wind vane base helps to monitor climate conditions in certain specific applications, further improving the safety and efficiency of operations.

Some application areas of Container Nitrogen Plant

Chemical industry

In the chemical industry, nitrogen, as an inert gas, has a wide range of important applications. Its primary role is to provide inert protection during chemical reactions to prevent the chemicals in the reactor from coming into contact with oxygen and undergoing oxidation reactions. Since many chemical reactions involve highly active substances that may cause fire or explosion when in contact with oxygen, the use of nitrogen effectively reduces the oxygen content in the reactor, creating a safe inert environment and preventing potential dangerous events. In addition, nitrogen also plays a vital role in the transportation of chemicals. During the transportation process, nitrogen is used to drive chemicals through the pipeline system to ensure that the chemicals do not come into contact with oxygen in the air while moving, thereby greatly reducing the risk of oxidation reactions and ensuring the safety and efficiency of transportation.

Nitrogen is also widely used in pressure testing of chemical equipment and pipeline systems. In these tests, nitrogen is used as a test medium. By pressurizing nitrogen, it is possible to detect whether there are leaks in the system and ensure the integrity and safety of the equipment. This method is not only safe and reliable, but can also effectively prevent leaks and accidents caused by equipment failures in actual production processes.

In addition, the role of nitrogen in the reaction termination process cannot be ignored. In some chemical reactions, it is crucial to terminate the reaction quickly to avoid overreaction or the formation of by-products. Nitrogen, through its inert properties, can quickly terminate the reaction and ensure that the reaction is completed at the expected time and under the expected conditions, thereby ensuring the quality and purity of the product. This application ensures precise control and high-quality output of chemical production processes.

Transportation and storage

Nitrogen plays a vital role in the transportation and storage process, especially when handling flammable and explosive substances. Since nitrogen is an inert gas, it can effectively exclude the presence of oxygen, thereby significantly reducing the risk of oxidation of substances, thereby reducing the possibility of fire and explosion. This property makes nitrogen an ideal choice for the storage and transportation of many chemicals and flammable liquids. In practical applications, storage tanks and transport tankers are often filled with nitrogen before loading flammable substances to create an oxygen-free environment, which not only protects the stored items but also ensures the safety of operators.

In addition, in many industrial processes, the use of nitrogen also helps to extend the shelf life of products. For example, in the petrochemical industry, the injection of nitrogen can prevent oil products from deteriorating due to oxidation during storage, thereby maintaining their quality and performance. In the field of food packaging, nitrogen is also widely used to prevent food from oxidizing and spoiling during storage. This method not only ensures the safety and stability of the product, but also reduces the potential economic losses caused by fire accidents. Therefore, the use of nitrogen not only improves safety during transportation and storage, but also ensures the effective management of chemicals and other flammable substances, becoming an indispensable part of modern industry.

Long-term storage

For substances that need to be stored for a long time, the protective effect of nitrogen is particularly important, especially in preventing oxidation and maintaining chemical stability. By maintaining a nitrogen atmosphere in the storage tank, the presence of oxygen can be effectively excluded, thereby preventing the stored substances from changing in quality or degrading in performance due to long-term exposure to oxygen. This is particularly critical for some sensitive chemicals. For example, some catalysts or drugs may lose their activity or produce harmful byproducts after contact with oxygen, thus affecting their effectiveness and safety.

The use of nitrogen can not only prevent the oxidation of chemicals, but also reduce the impact of moisture and other environmental factors on substances. In many industrial applications, especially in the fields of pharmaceuticals, chemicals and electronic materials, the inert properties of nitrogen can ensure that products remain in their ideal state during storage. This method greatly extends the shelf life of the substance and reduces economic losses caused by material deterioration.

Maybe you also want to know

Q: What is a Container Nitrogen Plant (CNP)?

A: It is a modular nitrogen production unit, usually designed in the form of a container, which is easy to transport and quickly deploy. It uses air separation technology to extract nitrogen from air by cooling and compressing it. This equipment is suitable for a variety of industrial applications, including chemicals, food packaging, metal processing, etc.

Q: How does CNP work?

A: The working principle of CNP is mainly based on the air separation process. First, the equipment inhales external air, and then compresses and cools the air through a compressor. At low temperatures, the oxygen and nitrogen in the air will liquefy, and then the nitrogen will be separated from other gases through technologies such as distillation or membrane separation, and finally output high-purity nitrogen. This process is not only efficient, but also relatively environmentally friendly.

Q: What are the main advantages of a nitrogen production plant?

A: It has multiple advantages. First, its modular design makes it easy to transport and install quickly, and it can be flexibly deployed according to demand. Secondly, the nitrogen production plant can provide a continuous and stable supply of nitrogen, avoiding dependence on external gas suppliers. In addition, the operating cost of the equipment is relatively low, which can significantly reduce the company's nitrogen procurement costs. Finally, it has a small footprint and can be used in environments with limited space.

Q: What industries are CNP suitable for?

A: CNP is suitable for a variety of industries, including but not limited to chemicals, oil and gas, food and beverage, metal processing, pharmaceuticals, and electronic manufacturing. In the chemical industry, nitrogen is used to prevent oxidation reactions; in food packaging, nitrogen can extend the shelf life; and in metal processing, nitrogen can be used for laser cutting and welding.

Q: What are the maintenance and care requirements of the nitrogen production plant?

A: The maintenance of the nitrogen production plant is relatively simple. Regular inspection and replacement of filters, monitoring gas purity, and checking the working status of compressors and cooling systems are routine maintenance tasks. In addition, comprehensive equipment inspections should be carried out regularly to ensure the normal operation of the system and extend the service life of the equipment.

Q: What is the energy consumption of CNP?

A: Its energy consumption is closely related to its design and application. Generally speaking, CNP consumes a certain amount of electricity during operation, but due to its efficient design, the energy consumption is usually lower than that of traditional nitrogen supply methods. Enterprises can further reduce energy consumption through reasonable usage plans and regular maintenance.

Q: How to choose a suitable nitrogen production plant?

A: When choosing a suitable nitrogen production plant, you need to consider several factors. First, evaluate the company's nitrogen needs, including flow and purity requirements. Second, consider the installation space and environmental conditions. Finally, choose a reputable supplier to ensure the quality of the equipment and after-sales service. At the same time, it is recommended to compare the technical parameters and cost-effectiveness of different models to make the decision that best meets your needs.

We're well-known as one of the leading container nitrogen plant manufacturers and suppliers in China. If you're going to buy high quality container nitrogen plant made in China, welcome to get more information from our factory.
