Psa Oxygen Generator
For Sea Bass Farming
√ Contact us now for a free consultation and a preferential quote!
√ NEWTEK, your trusted partner in aquaculture equipment!
►Efficient oxygen production, rapid increase of dissolved oxygen: Using imported molecular sieves, the oxygen purity is as high as 93%, the oxygen output speed is fast, and the dissolved oxygen content in the water is quickly increased to meet the high-density aquaculture needs of sea bass.
►Energy saving and environmental protection, reducing aquaculture costs: Compared with traditional oxygen production methods, it has lower energy consumption and lower operating costs, saving you a lot of electricity expenses.
►Intelligent Control, Worry-free And Labor-saving : Equipped with an intelligent control system, it can realize automatic operation, fault alarm, remote monitoring and other functions, which is simple to operate, worry-free and labor-saving.
►Stable And Reliable, Continuous Oxygen Supply : The core components are imported brands, with stable and reliable performance, and can operate continuously for 24 hours to ensure that the farm is continuously supplied with oxygen.
Model Selection |
||||||
No. |
Models |
Capacity (Nm3/hr) |
Purity |
Power consumption of 1Nm3 oxygen produced (kw/h) |
Number of bottles filled in 12 hours (pcs) |
Operator needed |
| 1 | NTK-5P | 5 | 93%+-3% | 3.54 | 10 | 2 |
| 2 | NTK-10P | 10 | 93%+-3% | 2.52 | 20 | 2 |
| 3 | NTK-15P | 15 | 93%+-3% | 2.31 | 30 | 2 |
| 4 | NTK-20P | 20 | 93%+-3% | 2.13 | 40 | 2 |
| 5 | NTK-25P | 25 | 93%+-3% | 2.01 | 50 | 2 |
| 6 | NTK-30P | 30 | 93%+-3% | 2.09 | 60 | 2 |
| 7 | NTK-40P | 40 | 93%+-3% | 1.81 | 80 | 2 |
| 8 | NTK-50P | 50 | 93%+-3% | 1.94 | 100 | 2 |
| 9 | NTK-60P | 60 | 93%+-3% | 1.62 | 120 | 2 |
| 10 | NTK-80P | 80 | 93%+-3% | 1.92 | 160 | 2 |
| 11 | NTK-100P | 100 | 93%+-3% | 1.83 | 200 | 2 |
| Design basis: Altitude：≤500m;RH：≤80%;Temperature：0℃-38℃;Filling pressure: 150Bar 40L Type Standard Cylinder | ||||||
FAQ
Q:What is the main role of PSA oxygen generator in sea bass farming?
A:PSA (pressure swing adsorption) oxygen generator separates high-purity oxygen by adsorbing nitrogen in the air, providing stable dissolved oxygen support for high-density breeding ponds. Its core functions include:
Maintaining dissolved oxygen levels in water: Sea bass has a high demand for dissolved oxygen (usually ≥5 mg/L), and PSA equipment can continuously supply oxygen 24 hours a day to avoid fish stress or death caused by lack of oxygen.
Increasing breeding density: Traditional oxygenation methods (such as impeller aerators) have limited efficiency. PSA systems can support higher-density breeding and increase unit output.
Q:Compared with traditional oxygen supply methods, what are the advantages of PSA technology?
A:PSA oxygen generators have the following significant advantages:
High efficiency and energy saving: Oxygen is separated by compressed air, and the energy consumption is lower than that of electrolyzed water or liquid oxygen transportation.
Automated control: Sensors can be integrated to monitor dissolved oxygen in real time, automatically adjust the oxygen supply, and reduce manual intervention.
Controllable purity: The oxygen purity can reach more than 90%, meeting the dissolved oxygen needs of different growth stages.
Q:How to choose the right PSA oxygen generator model according to the scale of aquaculture?
A:The following factors should be considered comprehensively when choosing:
Production demand: Small aquaculture ponds (such as 10 tons of water) can choose portable equipment with an oxygen production of 5-10 L/min; large farms (hundred tons) need to customize industrial-grade PSA systems (such as oxygen production ≥50 L/min).
Energy consumption and maintenance: Industrial-grade equipment needs to be equipped with a regulated power supply and regular molecular sieve replacement, and the maintenance cost is relatively high; small and medium-sized equipment pays more attention to energy efficiency.
Q:What matters need to be paid attention to in the operation and maintenance of PSA oxygen generators?
A:Key maintenance points include:
Air filtration: The front air filter needs to be cleaned regularly to prevent dust from clogging the molecular sieve.
Molecular sieve life: The adsorbent generally needs to be replaced every 2-3 years, depending on the frequency of use and ambient humidity.
System calibration: Regularly check the oxygen purity and flowmeter to ensure stable output.
Q:What is the specific impact of using PSA oxygen generators on the growth and aquaculture benefits of sea bass?
A:Practical applications show that:
Shorten the growth cycle: Stabilizing the dissolved oxygen environment can increase the feeding rate of sea bass and increase the average weight gain rate by 15%-20%.
Reducing mortality: The mortality rate caused by hypoxia has been reduced from 10% in the traditional model to less than 2%.
Fast cost recovery: Taking a farm with an annual output of 50 tons as an example, the investment in PSA equipment can be recovered through increased production and electricity saving within about 2 years.
