Modular design
supports uninterrupted switching of oxygen supply to ensure oxygen continuity in highly sensitive scenarios such as ICU and operating rooms (failure rate <0.01%/year)
AI early warning module
built-in sensors monitor oxygen concentration, humidity and equipment operating status in real time, predict the life of molecular sieves through algorithms, and trigger maintenance instructions in advance
30+
professional teams
100%
positive reviews
10k+
Order recieved
500+
Projects Completed
NEWTKE-NTK95 Series |
||||||
| No. | Models | Capacity (Nm3/hr) | Purity | Power consumption of 1Nm3 oxygen produced (kw/h) | Number of bottles filled in 12 hours (pcs) | Operator needed |
| 1 | NTK95-5P | 5 | 95%+-1% | 3.54 | 10 | 2 |
| 2 | NTK95-10P | 10 | 95%+-1% | 2.52 | 20 | 2 |
| 3 | NTK95-15P | 15 | 95%+-1% | 2.31 | 30 | 2 |
| 4 | NTK95-20P | 20 | 95%+-1% | 2.13 | 40 | 2 |
| 5 | NTK95-25P | 25 | 95%+-1% | 2.01 | 50 | 2 |
| 6 | NTK95-30P | 30 | 95%+-1% | 2.09 | 60 | 2 |
| 7 | NTK95-40P | 40 | 95%+-1% | 1.81 | 80 | 2 |
| 8 | NTK95-50P | 50 | 95%+-1% | 1.94 | 100 | 2 |
| 9 | NTK95-60P | 60 | 95%+-1% | 1.62 | 120 | 2 |
| 10 | NTK95-80P | 80 | 95%+-1% | 1.92 | 160 | 2 |
| 11 | NTK95-100P | 100 | 95%+-1% | 1.83 | 200 | 2 |
| Design basis: Altitude：≤500m;RH：≤80%;Temperature：0℃-38℃;Filling pressure: 150Bar 40L Type Standard Cylinder | ||||||
Deep adaptation of vertical medical scenarios
In response to the compliance and safety requirements of the medical industry, the product has passed the European Medical Equipment Quality Management System Certification and is adapted to the following scenarios
Emergency and intensive care
The instantaneous oxygen supply flow rate can reach 120L/min, meeting the needs of high-flow equipment such as ventilators and ECMO.
Grassroots medical sinking
Modular design supports flexible configuration of 10-500 beds, solving the pain point of lack of oxygen supply facilities in remote areas
Drug research and clinical trials
Commit to 4-hour fault response and 48-hour spare parts delivery to ensure the continuity of key medical services
Industry Value
Take a 300-bed general hospital as an example and compare it with the traditional liquid oxygen solution
| Indicators | 传统液氧方案 | NEWTEK PSA方案 |
|---|---|---|
| Annual oxygen supply cost | 1.8 million | 95k |
| Carbon emissions | 120 tons/year | 25 tons/year |
| Space occupancy | 80㎡ | 15㎡ |
Choosing NEWTEK is not just choosing a device, but also choosing the next generation of medical oxygen supply infrastructure.
